Building a simple Distributed System with Go & Consul

Having worked with a few Distributed Systems over the years such as Apache Kafka and Ethereum nodes I was wondering what it would take to build a minimal one. In this article we’ll be building a micro “kafka-like” distributed logging app with super simple features, using Go and Hashicorp Consul. You can follow along using this github repository.

Go + Consul: A solid combination for building Distributed Systems

What is Consul ?

Looking at the definition in the intro section of the official website:

Consul is a service mesh solution providing a full featured control plane with service discovery, configuration, and segmentation functionality

That might sound a bit scary, but don’t leave just yet. The main Consul feature we’ll use in this article is the Key/Value store, which will support our simple Leader Election system.

System Architecture

The diagram below shows the system’s architecture :

Distributed Loggers App Architecture

The system is composed of 3 parts:

• consul: Consul instance that provides support for leader election and service discovery.

• distributed-logger: The Distributed Logger nodes expose a REST API that logs received messages to Stdout. Only the cluster leader accepts messages at any given time. A new node takes over in case of leader node failure.

• producer: The producer queries Consul periodically to determine the distributed-logger leader and sends it a numbered message.

Demo

You can run the demo using docker-compose by pulling the repo and running:

$ docker-compose up -d --scale distributed-logger=3

What happens then is:

• The Consul instance is started.

• 3 distributed-logger instances are started and register a Session with Consul.

• A distributed-logger wins the election (in this case just because it’s faster in acquiring the lock from Consul) and becomes the Leader.

• The producer comes online, then polls Consul for the leader every 5 seconds and sends it a message.

• The leader receives the messages and logs it to Stdout

• If the leader dies or is killed via SIGTERM or SIGINT, a new distributed-logger node takes over as the leader and starts receiving messages from the producer

You can see an example below where Node 3 is the leader, then Node 2, then Node 1:

Distributed Loggers demo

Show me the code

The full code is available in the repo, but let’s look at a couple of interesting aspects of the app:

• To acquire leader status, each distributed-logger node runs a goroutine that tries periodically to acquire a lock in Consul:

for {
  if !isLeader {
    acquired, _, err := client.KV().Acquire(acquireKv, nil)
    if err != nil {
      log.Fatalf("kv acquire err: %v", err)
    }

    if acquired {
      isLeader = true
      log.Printf("I'm the leader !\n")
    }
  }

  time.Sleep(time.Duration(ttl/2) * time.Second)
}

• When signaled with SIGINT or SIGTERM, the distributed-logger nodes destroy their Consul Session, effectively releasing the lock and losing Leader status if the node was the Leader:

// wait for SIGINT or SIGTERM, clean up and exit
sigCh := make(chan os.Signal)
signal.Notify(sigCh, syscall.SIGINT, syscall.SIGTERM)

<-sigCh
close(doneCh)
log.Printf("Destroying session and leaving ...")
_, err = client.Session().Destroy(sID, nil)
if err != nil {
  log.Fatalf("session destroy err: %v", err)
}
os.Exit(0)

• The producer runs a loop to discover the Leader node and send messages:

for {
  kv, _, err := client.KV().Get(serviceKey, nil)
  if err != nil {
    log.Fatalf("kv acquire err: %v", err)
  }

  if kv != nil && kv.Session != "" {
    // there is a leader
    leaderHostname := string(kv.Value)
    sendMsg(leaderHostname, msgID)
    msgID++
  }

  time.Sleep(5 * time.Second)
}

Conclusion

Our little Proof of Concept is very far from being production ready. Distributed Systems is a very vast field and we are missing many aspects like: Replication, High Availability and solid Fault Tolerance.

That being said, I hope that you have enjoyed this example and that it will allow you to start diving into this complex topic and hopefully start building your own Distributed Systems ! Let me know of you have any questions or remarks.
